5
08/2005 ShopTurn Functions
5.5 Millin
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-241
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Position Select from 8 different positions:
End face/End face C – Front
End face/End face C – Rear
Peripheral surface/Peripheral surface C – Inner
Peripheral surface/Peripheral surface C – Outer
End face Y – Front (only when Y axis exists)
End face Y – Rear (only when Y axis exists)
Peripheral surface Y – inner (only when Y axis exists)
Peripheral surface Y – Rear (only when Y axis exists)
Clamp/release spindle (only for End face Y/Peripheral surface Y, and for End face
C/Peripheral surface C if the tool is inserted in the center for roughing)
The function must be set up by the machine manufacturer.
Machining
type
Roughing
Finishing
Finishing the edge
Chamfer
Einzelpos.
Pos. Muster
Mill circular pocket at the programmed position (X0, Y0, Z0, L0, C0, CP).
Mill several circular pockets in a positioning pattern (e.g. full circle or matrix).
X0
Y0
L0
C0
Z0
Z1
DXY
DZ
UXY
UZ
FS
ZFS
Single position End face/End face C:
The reference point is always the center point of the circular pocket.
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Pocket depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the XY plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (pocket edge) – (for roughing and finishing only)
Finishing allowance in depth (pocket base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
mm
Degrees
mm
mm
mm
%
mm
mm
mm
mm
mm
Y0
C0
Z0
X0
X1
DYZ
DX
Single position Peripheral surface/Peripheral surface C:
The reference point is always the center point of the circular pocket.
Reference point in Y direction (abs.)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Cylinder diameter ¬ (abs.)
Pocket depth based on X0 ¬ (abs or inc) – (only for roughing and finishing)
Maximum infeed in the YZ plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction) – (for roughing and finishing only)
mm
Degrees
mm
mm
mm
mm
%
mm
