5
08/2005 ShopTurn Functions
5.5 Millin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-255
Full circle
Pitch circle
Position slots around a full circle. The slot spacing is uniform and is calculated by
the control.
Position slots around a pitch circle. The slot spacing can be determined on the basis
of angle α2.
X0
Y0
L0
C0
Z0
Z1
DZ
UXY
FS
ZFS
End face/End face C:
The reference point is always the center point of the full or pitch circle.
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Slot depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Chamfer width (abs) – (for chamfer only)
Insertion depth for the drill tip (abs or inc) -- (only for chamfer)
mm
mm
mm
Degrees
mm
mm
mm
mm
mm
mm
Y0
C0
Z0
X0
X1
DX
UYZ
FS
ZFS
Peripheral surface/Peripheral surface C:
The reference point is always the center point of the full or pitch circle.
Reference point in Y direction (abs.)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Cylinder diameter ¬ (abs.)
Slot depth based on X0 ¬ (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Chamfer width (abs) -- (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
Degrees
mm
mm
mm
mm
mm
mm
mm
CP
X0
Y0
L0
C0
Z0
Z1
DZ
UXY
FS
ZFS
End face Y:
The reference point is always the center point of the full or pitch circle.
Positioning angle for machining area
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Slot depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Chamfer width (abs) -- (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
Degrees
mm
mm
mm
mm
mm
mm
