5
ShopTurn Functions 08/2005
5.6 Contour millin
g
5
Siemens AG, 2005. All rights reserved
5-290 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
X0
X1
DYZ
UYZ
Reference point in X direction (abs.)
Depth with reference to X0 (inc.)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Finishing allowance in plane
mm
mm
mm
%
mm
Retraction
mode
If more than one insertion point is necessary, specify the retraction height to which
the tool retracts between insertion points:
To retraction plane
Z0+safety clearance (for end face/end face C and end face Y only) or
X0+safety clearance (for peripheral surface/peripheral surface C and peripheral
surface Y only)
If there are no islands larger than Z0 (X0) in the pocket area, Z0 + safety clearance
(X0 + safety clearance) can be programmed as the retraction mode.
Predrilling
Contour
milling >
Predrilling
>
Predrilling
¾ Press the "Milling", "Contour Milling", "Predrilling" and "Predrilling"
soft keys in this order.
All
parameters
¾ Press the "All Parameters" soft key if you want to enter additional
parameters.
Parameters Description of predrilling Unit
T, D, F, S, V See Sec. "Creating program blocks".
Position Select from 8 different positions:
End face/End face C – Front
End face/End face C – Rear
Peripheral surface/Peripheral surface C – Inner
Peripheral surface/Peripheral surface C – Outer
End face Y – Front (only when Y axis exists)
End face Y – Rear (only when Y axis exists)
Peripheral surface Y – inner (only when Y axis exists)
Peripheral surface Y – Rear (only when Y axis exists)
Clamp/release spindle
The function must be set up by the machine manufacturer.
TR Reference tool for predrilling
D Cutting edge of reference tool (1 or 2)
Z0
Z1
DXY
UXY
UZ
End face/End face C:
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
%
mm
mm
