08/2005 ShopTurn Functions
5.6 Contour millin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-293
DZ
UXY
UZ
Maximum depth infeed (Z direction)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
X0
X1
DYZ
DX
UYZ
UX
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Depth with reference to X0 ¬ (abs. or inc.)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
%
mm
mm
mm
CP
Z0
Z1
DXY
DZ
UXY
UZ
End face Y:
Reference point
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction)
Finishing allowance in plane
Finishing allowance in depth
Degrees
mm
mm
mm
%
mm
mm
mm
C0
X0
X1
DYZ
DX
UYZ
UX
Peripheral surface Y:
Reference point
Reference point in X direction (abs.)
Depth with reference to X0 (abs. or inc.)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction)
Finishing allowance in plane
Finishing allowance in depth
Degrees
mm
mm
mm
%
mm
mm
mm
Starting point
X
Y
Y
Z
Determine start point automatically or enter it manually
Manual entry allows for a start point outside the pocket, whereby straight line
machining into the pocket is performed first, e.g. for a pocket with a side opening
without any insertion.
Start point X (abs.) – (only for end face/end face C and end face Y with manual start
point)
Start point Y (abs.) – (only for end face/end face C and end face Y with manual start
point)
Start point Y (abs.) – (only for peripheral face/peripheral face C and peripheral face
Y with manual start point)
Start point Z (abs.) – (only for peripheral face/peripheral face C and peripheral face
Y with manual start point)
mm
mm
mm
mm
