Page #304 background image
5
ShopTurn Functions 08/2005
5.6 Contour millin
g
5
Siemens AG, 2005. All rights reserved
5-304 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Z0
Z1
DXY
DZ
UXY
UZ
End face/End face C:
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
%
mm
mm
mm
X0
X1
DYZ
DX
UYZ
UX
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Depth with reference to X0 ¬ (abs. or inc.)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
%
mm
mm
mm
CP
Z0
Z1
DXY
DZ
UXY
UZ
End face Y:
Reference point
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction)
Finishing allowance in plane
Finishing allowance in depth
Degrees
mm
mm
mm
%
mm
mm
mm
C0
X0
X1
DYZ
DX
UYZ
UX
Peripheral surface Y:
Reference point
Reference point in X direction (abs.)
Depth with reference to X0 (abs. or inc.)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction)
Finishing allowance in plane
Finishing allowance in depth
Degrees
mm
mm
mm
%
mm
mm
mm
Retraction
mode
If more than one approach point is necessary, specify the retraction height to which
the tool retracts between approach points.
To retraction plane
Z0+safety clearance (for end face/end face C and end face Y only) or
X0+safety clearance (for peripheral surface/peripheral surface C and peripheral
surface Y only)
If there are no spigots or other elements in the machining range higher than Z0 (X0),
Z0 + safety clearance (X0 + safety clearance) can be programmed as the retraction
mode.
