Siemens MCP 398C Operation/Programming

5
08/2005 ShopTurn Functions
5.6 Contour millin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-311
Machining
mode
Chamfer
Z0
FS
ZFS
End face/End face C:
Reference point in Z direction (abs.)
Chamfer width; abs
Insertion depth tool tip; abs or inc
mm
mm
mm
X0
FS
ZFS
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Chamfer width; abs
Insertion depth tool tip; abs or inc
mm
mm
mm
CP
Z0
FS
ZFS
End face Y:
Reference point
Reference point in Z direction (abs.)
Chamfer width; abs
Insertion depth tool tip; abs or inc
Degrees
mm
mm
mm
C0
X0
FS
ZFS
Peripheral surface Y:
Reference point
Reference point in X direction (abs.)
Chamfer width; abs
Insertion depth tool tip; abs or inc
Degrees
mm
mm
mm
Retraction
mode
If more than one insertion point is necessary, specify the retraction height to which
the tool retracts between insertion points:
 To retraction plane
 Z0+safety clearance (for end face/end face C and end face Y only) or
X0+safety clearance (for peripheral surface/peripheral surface C and peripheral
surface Y only)
If there are no islands larger than Z0 (X0) in the pocket area, Z0 + safety clearance
(X0 + safety clearance) can be programmed as the retraction mode.
