7
G Code Program 08/2005
7.1 Creatin
a G-code
ro
ram
7
♥ Siemens AG, 2005. All rights reserved
7-346 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Edit
Select the "Edit" softkey if you want to return directly to the G code
editor from a parameter screen form.
Measuring cycle support
îš¾ Switch to the extended horizontal softkey bar.
Measure
turning
-or-
Measure
milling
îš¾ Press the "Measure turning" or "Measure milling".
Calibrate
meas. cal.
...
îš¾ Select the required measuring cycle via the softkey.
îš¾ Enter the parameters.
OK
îš¾ Press the "OK" softkey.
The measuring cycle is transferred to the editor as G code.
îš¾ Position the cursor on a measuring cycle in the G code editor, if
you want to display the associated parameter screen form again.
Re-
compile
îš¾ Select the "Recompile" softkey.
The parameter screen for the selected measuring cycle appears.
Edit
Select the "Edit" softkey if you want to return directly to the G code
editor from a parameter screen form.
Online help (PCU 50.3)
îš¾ Place the cursor on a G code command in the G code editor or on
an input field in a cycle support parameter screen form.
îš¾ Press the "Help" key.
The relevant help screen is displayed.
