8
Tool Management 08/2005
8.5 Loadin
/unloadin
a tool into/out of the ma
azine
8
♥ Siemens AG, 2005. All rights reserved
8-366 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
-or-
îš¾ Enter the location number you require and press the "OK" softkey.
-or-
Spindle
îš¾ Press the "Spindle" and "OK" softkeys to load a tool into the
spindle.
The tool is loaded into the specified magazine location.
Finding an empty
location in the magazine
and loading the tool
îš¾ Select the "Tool list" softkey in the "Tools WOs" operating area.
îš¾ Place the cursor on the tool that you want to load into the
magazine.
Load
îš¾ Press the "Load" softkey.
The "Empty location" window appears. The "Location" field is
initialized with the number of the first empty magazine location.
îš¾ Enter the magazine number and a "0" for the location number if
you wish to search for an empty location in a particular magazine.
-or-
îš¾ Enter a "0" for the magazine number and location number if you
wish to search for an empty location in all magazines.
îš¾ Press the "OK" softkey.
An empty location is suggested.
îš¾ Press the "OK" softkey.
The tool is loaded into the suggested magazine location.
Unloading an individual
tool from the magazine
îš¾ Select the "Tool list" softkey in the "Tools WOs" operating area.
îš¾ Position the cursor on the tool that you want to unload.
Unload
îš¾ Press the "Unload" softkey.
The tool is unloaded from the magazine.
