9
Program Management 08/2005
9.3 Mana
in
ro
rams with PCU 50.3
HMI Advanced
9
♥ Siemens AG, 2005. All rights reserved
9-388 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
You can display the directories and programs of the following storage
media:
USB/Network-drives (network card required)
Floppy disk drive
Local USB front interface
The hard disk as archive directory.
Please also refer to the machine manufacturer's instructions.
In the overview, the symbols in the left-hand column have the
following meaning:
Directory
Program
Zero point/tool data
The directories and programs are always listed complete with the
following information:
Name
The name can be up to 24 characters long. For data transfer to
external systems, the name is truncated to 8 characters.
Type
Directory: WPD
Program: MPF
Zero point/tool data: INI
Loaded
At a cross in the "Loaded" column, you will see whether the
program is still in the NCK work memory (X) or whether it is on the
hard-disk ( ).
Size (in bytes)
Date/time (of creation or last change)
You can find additional information for data-handling, selecting and
executing a program in:
References: /BAD/, Operating Instructions HMI Advanced.
In the "TEMP" directory, ShopTurn stores the programs that are
created internally for calculating the stock removal processes.
Above the horizontal softkey bar, you will find specifications for
memory space management on the hard-disk and in the NCK.
