9
Program Management 08/2005
9.3 Mana
in
ro
rams with PCU 50.3
HMI Advanced
9
♥ Siemens AG, 2005. All rights reserved
9-400 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
îš¾ Press the "OK" softkey.
The data are read in.
Depending on which data you have selected, ShopTurn behaves as
follows:
All tool offset data
First, all tool management data is deleted and then the saved data are
read-in.
All tool offset data used in the program
If at least one of the tools to be read in already exists in the tool
management system, you can choose between the following options.
Replace all
îš¾ Select the "Replace all" softkey to import all tool data. Any existing
tools will now be overwritten without a warning prompt.
-or-
Replace
none
îš¾ Select the "Replace none" softkey if you want to cancel the data
import.
-or-
îš¾ Select the "No" softkey if you want to keep the old tool.
If the old tool is not at the saved magazine location, it is relocated
there.
-or-
îš¾ Select the "Yes" softkey if you want to overwrite the old tool.
With the tool management option without loading/unloading, the old
tool is deleted; the old tool is unloaded beforehand in the variant with
loading/unloading.
If you change the tool name before importing it with "Yes", the tool will
be added as an extra tool to the tool list.
Work offsets
Existing work offsets are always overwritten when new offsets are
imported.
Magazine loading
If magazine loading data are not imported at the same time, tools are
entered in the tool list without a location number.
îš„
