11
08/2005 Examples
11.1 Standard machinin
g
p
rocesses
11
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 11-409
Program
1. Create a new program  In the "Program manager" operating area, in the desired directory,
press the
New
and
ShopTurn
program
softkeys.
 Program name (here: Enter demo part_1)
 Press the
softkey
2. Program header The parameter screen form “Program Header” is displayed.
 Define the blank:
Blank
Cylinder
XA
90 abs
ZA
0 abs
ZI
-120 abs
ZB
-100 abs
Retraction
simple
XRA
2 inc.
ZRA
5 inc.
Tool Change Point
Machine (MCS)
XT
160 abs
ZT
409 abs
SC
1 inc.
S1
4000 rpm
Unit of
measurement
mm
 Press the
softkey
3. Stock removal cycle for
facing
 Press the
Stock
removal
softkeys
 Enter parameters:
T
Roughing tool_80
F
0.300 mm/rev
V
300 m/min
Machining
Position
Direction
Plan (parallel to the X-axis)
X0
60 abs
Z0
2 abs
X1
-1.6 abs
Z1
0 abs
D
2 inc.
UX
0 inc.
UZ
0.1 inc.
