11
08/2005
Examples
11.1
Standard machinin
g
p
rocesses
11
♥
Siemens AG, 2005. All rig
hts reserved
SINUMERIK 840D sl
Operation/Progra
mming ShopTurn (BA
T) – 08/2005 Editio
n
11-415
Recess
10.
Groove (finishing)
îš¾
Press
the
Groove
softkeys
îš¾
Enter
parameters:
T
Recessing t
ool
F
0.150 mm/rev
V
300 m/min
Machining
Groove
position
Reference
point
X0
60 abs
Z0
-70
B1
5.856 inc.
T1
4 inc.
α
1
15 degree
α
2
15 degree
FS1
1
R2
1
R3
1
FS4
1
N
1
îš¾
Press
the
softkey
11.
Longitudinal t
hreads
M48x2
(roughing)
îš¾
Press
the
Thread
Thread
long.
softkeys
îš¾
Enter
parameters:
T
Threading tool_2
P
2 mm/rev
414
416
