Siemens MCP 398C Operation/Programming

2
Setting Up the Machine 08/2005
2.7 Zero-
p
oint offsets
2
♥ Siemens AG, 2005. All rights reserved
2-76 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Coordinate
transformations
Program The active coordinates of the "Offset" transformation are displayed as
well as the angle set in the "Rotation" transformation by which the
coordinate system rotates.
You cannot edit these values here.
Scale The active scaling factor for the "Scaling" transformation is displayed
for the respective axis.
You cannot edit these values here.
Mirror The mirror axis that was defined by means of the "Mirroring"
transformation is displayed.
You cannot edit these values here.
Total offset
Total The total offset resulting from the base offset and all active work
offsets and coordinate transformations appears.
Further
axes
With the "Further axes" softkey, you can display another three axes (2
round axes, 1 linear axis) and determine their offsets. These additional
axes must be activated via machine data.
Please also refer to the machine manufacturer's instructions.
 Select the "Work offset" softkey in the "Tools WOs" operating
section.
The work offset list appears.
