Siemens MCP 398C Operation/Programming

3
08/2005 Machining the Workpiece
3.5 Startin
g
the machinin
g
at a s
p
ecific
p
oint in the
p
ro
g
ram
3
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 3-99
 Press the "Block search" softkey.
To
contour
...
External -
without cal.
 Select a calculation technique.
Cycle Start
 Press the "Cycle Start" key.
ShopTurn carries out all necessary pre-settings.
Cycle Start
 Press the "Cycle Start" key again.
The new starting position is approached. The program executes from
the beginning or end of the target block, depending on the calculation
technique.
Reset
You can abort the search by pressing the "Reset" key.
Select point of interruption
Program execution must have been interrupted by pressing the
"Reset" key. (ShopTurn automatically remembers this point of
interruption.)
 Switch back to "Machine Auto" mode.
Search
pointer
 Press the "Block search" and "Search pointer" softkeys.
Interrupt
point
 Press the "Interrupt point" softkey.
ShopTurn inserts the saved interrupt point as a target.
To
contour
...
External -
without cal.
 Select a calculation technique.
Cycle Start
 Press the "Cycle Start" key.
ShopTurn carries out all necessary pre-settings.
Cycle Start
 Press the "Cycle Start" key again.
The new starting position is approached. The program executes from
the beginning or end of the target block, depending on the calculation
technique.
Reset
You can abort the search by pressing the "Reset" key.
