Appendices
Appendix G
-
MD
-
BMED with Visual Display
103
Building Technologies 125-202
06/06/2017
Display Configuration Instructions
Mode Selection: The meter display can be toggled between an “Auto Cycle” mode
(default) or “Manual Cycle and Hold” mode by pushing/holding the meter display button
for >5 seconds, This mode change is saved to non volatile memory in case of power
loss.
Auto Cycle: The display will auto cycle between flowchart screens every 2 seconds.
Pushing the meter display button < 5 seconds will serve to temporarily “hold” the
current screen until either the display button is pushed again or until a 20-second
default timeout occurs, returning it to auto cycle.
Manual Cycle and Hold: The display will advance the flowchart screens using a manual
means, by pushing the meter display button multiple times. The display screen will
remain in the last displayed mode, updating values continuously.
