Installation
40
Building Technologies 125-202
06/06/2017
Installation
Once the MD-BMS or MD-BMED Power Meter is set up for the desired communication
method and protocol, it is ready to be installed.
WARNING
Remove the meter from all power sources before mounting.
Mounting the MD-BMS and MD-BMED Power Meters
The MD-BMS and MD-BMED Power Meters must be installed in an approved electrical
panel or enclosure using proper installation practices according to the NEC and local
electrical codes.
1. To mount the meter, use the two tabs provided at each end of the case or mount
on a 35 mm Top Hat mounting DIN rail (EN 50022).
2. Securely mount the meter near a dedicated circuit disconnect breaker.
