BMED Power Meters BACnet Analog Value Objects
72
Building Technologies 125-202
06/06/2017
Object
Identifier
Name Description
2100 kWh L3 Positive "
6010 kVARh System System Total Reactive Energy (Signed)
6020 kVARh Sys Total Pos System Total Positive Apparent Energy (kVAh) (Signed
Net) Accumulates only when kVAh is positive.
6050 kVARh L1 Positive Individual Phase Reactive Energy (kVAR) (Signed)
6080 kVARh L2 Positive "
6110 kVARh L3 Positive "
7001 kVAh System Total Positive System Total Positive Apparent Energy (kVAh) (Signed
Net). Accumulates only when kW is present.
7020 kVAh L1 Positive Individual Phase Apparent Energy LSW (kVAh) (Signed)
7050 kVAh L2 Positive "
7080 kVAh L3 Positive "
Negative Power/Energy Accumulator Objects
Object
Identifier
Name Description
1090 Negative kW System Average Equals kWh System Negative/(Time Since
Reset/3600 seconds/Hr) (resettable).
1120 kW System Maximum Negative System Highest Instantaneous Negative Draw Since
Reset (kW)
1150 kW System Minimum Negative System Lowest Instantaneous Negative Draw Since
Reset (kW, resettable)
2020 kWh System Total Negative System True Energy (kWh) Negative (Signed Net)
2050 kWh L1 Negative Individual Phase True Energy (kWh) (Signed)
2080 kWh L2 Negative "
2110 kWh L3 Negative "
6030 kVARh Sys Negative System Total Reactive Energy (Signed Net)
6060 kVARh L1 Negative Individual Phase Reactive Energy (kVARh) (Signed)
6090 kVARh L2 Negative "
6120 kVARh L3 Negative “
7002 kVAh System Total Negative System Total Negative Apparent Energy (Signed
Net). Accumulates only when kW is negative.
7030 kVAh L1 Negative Individual Phase Apparent Energy LSW (kVAh)
(Signed)
