Appendices
Appendix A
-
MD
-
BMS and MD
-
BMED Power Meters BACnet Analog Value Objects
71
Building Technologies 125-202
06/06/2017
Pulse Output/Input Objects
Object
Identifier
Name Description
13020 Port 1 output control when used as an on/off-
open/closed switch
0 = Output LOW (closed)
1 = Output HIGH (open) [default]
Object 13100 present value must = 0 to use.
13100 Digital Port 1 Configuration
Turns pulses on/off
0 = No pulses, Port may be used as an on’/off-
open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
13110 Port 1 pulse output relay type 0 = Normally open (HIGH)
1 = Normally closed (LOW)
14014 BBMD IP Address LSW object identifier
14015 BBMD IP Address MSW object identifier
Device Status Objects
Object
Identifier
Name Description
10080 Hardware ID Hardware revisions
10090 Features New features
10130 Reset Processor Processor reset
10150 MD Model Power Meter Element
ID
Used for ViewPoint to determine which element is
being read and total number of elements available.
Element index multiplied by 256 + number of elements.
Positive Power/Energy Accumulator Objects
Object
Identifier
Name Description
1080 kW System Average Positive Equals kWh System Positive/(Time Since Reset/3600
seconds/Hr) (resettable) (Signed Net)
1110 kW System Maximum Positive System Highest Instantaneous Positive Draw Since Reset
(kW) (Signed Net)
1140 kW System Minimum Positive System Lowest Instantaneous Positive Draw Since Reset
(kW, resettable)
2010 kWh System Total Positive System True Energy (kWh) Positive (Signed Net)
2040 kWh L1 Positive Individual Phase True Energy (kWh) (Signed)
2070 kWh L2 Positive "
