Appendices
Appendix J
-
Core Measurement Parameters: Power Factor
111
Building Technologies 125-202
06/06/2017
Measurement Parameters: Power BACnet
Object
Identifier
Modbus
Register
Modbus
Offset
(Offset to a
Base of 40001)
NOTES:
If avg kW value>0, avg positive kW = avg kW, avg negative kW = 0
If avg kW value<0, avg negative kW = avg kW , avg positive kW = 0)
System Maximum Power Draw (kW System Max)
system highest instantaneous power draw since reset, in kW (resettable)
= max kW net value, signed, BACnet
= positive max KW value, signed, BACnet
= negative max kW value, signed, BACnet
= max kW value, unsigned
= positive max kW value, unsigned
= negative max kW value, unsigned
NOTES:
If max kW value>0, max positive kW = max kW, max negative kW = 0
If max kW value<0, max negative kW = max kW , max positive kW = 0
1100
1110
1120
‒
‒
‒
‒
‒
‒
44006
46006
47006
‒
‒
‒
4005
6005
7005
System Minimum Power Draw (kW System Min)
system lowest instantaneous power draw since reset in kW (resettable)
= min kW net value, signed, BACnet
= positive min kW value, signed, BACnet
= negative min kW value, signed, BACnet
= min kW value, unsigned
= positive min kW value, unsigned
= negative min kW value, unsigned
NOTES:
If min kW value>0, min positive kW = min kW, min negative kW = 0
If min kW value<0, min negative kW = min kW , min positive kW = 0
1130
1140
1150
‒
‒
‒
‒
‒
‒
44007
46007
47007
‒
‒
‒
4006
6006
7006
Individual Phase Instantaneous True Power- L1 (kW L1)
= total kW L1 value, signed, individual L1 phase true power in kW, BACnet
= total kW L1 value, unsigned, individual L1 phase true power, in kW
= positive kW L1 value, unsigned, individual L1 phase true power, in kW
= negative kW L1 value, unsigned, individual L1 phase true power, in kW
NOTES:
If kW L1 value>0, positive kW L1 = total kW L1, negative kW L1 = 0
If kW L1 value<0, negative kW L1 = total kW L1, positive kW L1 = 0
1160
‒
‒
‒
‒
44029
46029
47029
‒
4028
6028
7028
Individual Phase Instantaneous True Power- L2 (kW L2)
= total kW L2 value, signed, individual L2 phase true power in kW, BACnet
= total aPF L2 value, unsigned, individual L2 phase true power, in kW
= positive kW L2 value, unsigned, individual L2 phase true power, in kW
= negative kW L2 value, unsigned, individual L2 phase true power, in kW
NOTES:
If kW L2 value>0, positive kW L2 = total kW L2, negative kW L2 =0
If kW L2 value<0, negative kW L2 = total kW L2, positive kW L2 =0
1190
‒
‒
‒
‒
44030
46030
47030
‒
4029
6029
7029
Individual Phase Instantaneous True Power- L3 (kW L3)
= total kW L3 value, signed, individual L3 phase true power in kW, BACnet
= total kW L3 value, unsigned, individual L2 phase true power, in kW
= positive kW L3 value, unsigned, individual L2 phase true power, in kW
= negative kW L3 value, unsigned, individual L2 phase true power, in kW
NOTES:
If kW L3 value>0, positive kW L3 = total kW L3, negative kW L3 = 0
If kW L3 value<0, negative kW L3 = total kW L3, positive kW L3 = 0
1220
‒
‒
‒
‒
44031
46031
47030
‒
4030
6030
7030
