Appendices
Appendix B
-
MD
-
BMS and MD
-
BMED Power Meters Modbus Absolute/Net Value Measurement Registers and
Protocol Commands
75
Building Technologies 125-202
06/06/2017
Modbus Offset Register Description
44020 4019 Volts L2 to L3 Individual Phase to Phase Voltage
44021 4020 Volts L1 to L3 "
44022 4021 Line Frequency Line Frequency (Hz)
44023 4022 kWh L1 LSW Individual Phase True Energy LSW (kWh)
44024 4023 kWh L1 MSW Individual Phase True Energy MSW (kWh)
44025 4024 kWh L2 LSW "
44026 4025 kWh L2 MSW "
44027 4026 kWh L3 LSW "
44028 4027 kWh L3 MSW "
44029 4028 kW L1 Individual Phase True Powers (kW)
44030 4029 kW L2 "
44031 4030 kW L3 "
44032 4031 kVARh L1 LSW Individual Phase Reactive Energy LSW (kVARh)
44033 4032 kVARh L1 MSW Individual Phase Reactive Energy MSW (kVARh)
44034 4033 kVARh L2 LSW "
44035 4034 kVARh L2 MSW "
44036 4035 kVARh L3 LSW "
44037 4036 kVARh L3 MSW "
44038 4037 kVAR L1 Individual Phase Reactive Powers (kVAR)
44039 4038 kVAR L2 "
44040 4039 kVAR L3 "
44041 4040 kVAh L1 LSW Individual Phase Apparent Energy LSW (kVAh)
44042 4041 kVAh L1 MSW Individual Phase Apparent Energy MSW (kVAh)
44043 4042 kVAh L2 LSW "
44044 4043 kVAh L2 MSW "
44045 4044 kVAh L3 LSW "
44046 4045 kVAh L3 MSW "
44047 4046 kVA L1 Individual Phase Apparent Powers (kVA)
44048 4047 kVA L2 "Individual Phase Apparent Powers
44049 4048 kVA L3 "
44050 4049 Displacement PF L1 Individual Phase displacement Power Factor (PF)
