Appendices
Appendix B
-
MD
-
BMS and MD
-
BMED Power Meters Modbus Absolute/Net Value Measurement Registers and
Protocol Commands
85
Building Technologies 125-202
06/06/2017
Modbus Offset Register Description
47037 7036 Negative kVARh L3 MSW "
47038 7037 Negative kVAR L1 Individual Phase Negative Instantaneous
Reactive Powers (kVAR)
47039 7038 Negative kVAR L2 "
47040 7039 Negative kVAR L3 "
47041 7040 kVAh L1 LSW Individual Phase Apparent Energy LSW (kVAh,
resettable)
47042 7041 kVAh L1 MSW Individual Phase Apparent Energy MSW (kVAh,
resettable)
47043 7042 kVAh L2 LSW “
47044 7043 kVAh L2 MSW “
47045 7044 kVAh L3 LSW “
47046 7045 kVAh L3 MSW “
47047 7046 kVA L1 Individual Phase Instantaneous Apparent
Powers (kVA)
47048 7047 kVA L2 “
47049 7048 kVA L3 “
47050 7049 Negative Displacement PF L1 Individual Phase Negative Displacement Power
Factors (dPF); Register is 100 × actual value (If
the Individual dPF(44050) is Negative, this
register will contain that value; otherwise, it will
be zero).
47051 7050 Negative Displacement PF L2 "
47052 7051 Negative Displacement PF L3 "
47053 7052 Negative Apparent PF L1 Individual Phase Negative Apparent Power
Factors (aPF); Register is 100 × actual value (If
the Individual aPF (44053) is Negative, this
register will contain that value; otherwise, it will
be zero).
47054 7053 Negative Apparent PFL2 "
47055 7054 Negative Apparent PF L3 "
47056 7055 Amps L1 Individual Phase Instantaneous Currents (A)
47057 7056 Amps L2 “
47058 7057 Amps L3 “
47059 7058 Volts L1 to Neutral Individual Instantaneous Phase to Neutral
Voltages (V)
47060 7059 Volts L2 to Neutral “
