2 Operating elements of the
central communication unit
2.1 Housing
2.1.1 Unit front
12 34
5
6
7
2841Z25
1 Buttons on the left
2 Display
3 Buttons on the right
4 FILE button (with no function)
5 Operating cards
6 Lock
7 Sealable fixing screw
To access the cable strips inside the unit, undo the sealable
fixing screw and open the housing (also refer to subsection
“3.1.3 Electrical installation“).
Note
