Building Technologies User Manual OCI600 74 319 0002 0 c
HVAC Products Setting up the OCI600 with the ACS7.. software 15.07.2005
The inputs of “Input module 1“ through “Input module 4“ of
“Log. inputs OCI600“ and “Inputs OCI600“ (digital inputs) can
be switched to the 2 “Outputs OCI600“ (digital outputs).
If the states of several inputs are forwarded to the same re-
lay, the relay will stay active until all inputs are inactive. This
way, a common alarm can be implemented.
A relay used in this way cannot simultaneously be controlled
manually or by a 7-day program. Control via inputs has the
highest priority.
4.2.8 Parameterizing the logical inputs
The 4 “Logical inputs of the OCI600“ have the following de-
fault meaning:
Input Meaning
1: Communication
error
Here, the response of the OCI600
to an internal fault in the OCI600
itself is parameterized (error code
80-99).
2: LPB device fault Here, the response of the OCI600
to an alarm message delivered by
a controller connected to the LPB
and entered in the OCI600 is pa-
rameterized.
1)
3: Sensor fault Here, the response of the OCI600
to an error message delivered by
a temperature sensor connected
to the bus is parameterized.
4: SYNERGYR fault Here, the response of the OCI600
to an error message delivered by
an OZW30 central unit connected
to the bus is parameterized.
1)
The controller delivers an alarm message to the bus only if the priority of
its own fault is sufficient
Linking inputs
with outputs
Note
Default
meanings
