Introduction
1.2Description
5
Fast Ethernet Ports
6
ANT2 Port
7
SFP Transceiver Ports
8
Failsafe Alarm Relay
9
ANT3 Port
10
ANT4 Port
11
Power Supply Terminal Block
12
RS232 Serial Console Port (DB9)
13
ANT5 Port
14
POWER LED
15
ALARM LED
16
CELL LED
Figure1.1 RUGGEDCOM RX1400
POWER LED Illuminates when power is being supplied to the device.
ALARM LED Illuminates when an alarm condition exists.
CELL LED Indicates when the cellular modem is connected to the network.
• Solid = Activity
• Off = No activity
Port Status LEDs Indicate the status of each port:
State Description
Solid Link established
Blinking Link activity
Off No link/activity
Access Plate The removable access plate provides access to the Micro SD card
and SIM card slots.
• Use a Micro SD card to store the firmware and configuration for
the device
• Use a single or dual (recommended) SIM cards to connect to an
LTE network
RS232 Serial Console Port The serial console port is for interfacing directly with the device and
accessing initial management functions. For information about con-
necting to the device via the serial console port, refer to "Connect-
ing to the Device (Page 25)".
ANT Ports SMA ports for connecting to an LTE network or Global Navigation
Satellite System (GNSS). For more information, refer to:
• "Connecting the Antennas (Page 13)"
• "Cellular Modem Specifications (Page 36)"
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 21)"
• "Failsafe Alarm Relay Specifications (Page 35)"
Power Supply Terminal Block A pluggable terminal block. For more information, refer to:
• "Connecting Power (Page 22)"
• "Power Supply Specifications (Page 35)"
RUGGEDCOM RX1400
Installation Manual, 09/2019, C79000-G8976-1103-13
3
