Installing the Device
2.5.3Connecting LTE Antennas
Antenna Type Operating
Frequen-
cy (GHz)
Gain (dBi) Article Number Reference
2.4 3.0ANT795-4MA Omni-Di-
rectional
5.0 5.0
6GK5795-4MA00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/61199227
2.4 3.0ANT795-4MC Omni-Di-
rectional
5.0 5.0
6GK5795-4MC00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/61199227
2.4 3.0ANT795-4MD Omni-Di-
rectional
5.0 5.0
6GK5795-4MD00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/61199227
2.4 2.0ANT795-4MX Omni-Di-
rectional
5.0 2.5
6GK5795-4MX00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/102325861
2.4ANT795-6DC Directional
5.0
a
9.0 6GK5795-6DC00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/60510336
Directional 2.4 6.0AN-
T795-6MN
b
Omni-Di-
rectional
5.0
a
8.0
c
6GK5795-6MN10-0AA6 https://support.indus-
try.siemens.com/cs/ww/en/-
view/26536615
Directional 2.4 5.0AN-
T795-6MT
b
Omni-Di-
rectional
5.0
a
7.0
g
6GK5795-6MT00-0AA0 https://support.indus-
try.siemens.com/cs/ww/en/-
view/60510908
a
Not for use in Canada.
b
Must always be used with a 5 m (16 ft) cable (6X1875-5CH50).
c
Total gain is 3.6 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
d
Must always be used with a 10 m (33 ft) cable (6X1875-5CN10).
e
Total gain is 9.2 dBi when connected via a 10 m (33 ft) cable (6X1875-5CN10) with an 8.8 dB loss.
f
Total gain is 9.1 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
g
Total gain is 2.6 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
2.5.3 Connecting LTE Antennas
Install a single 4G LTE (Long Term Evolution) antenna for Single-Input Single-Output
(SISO) or dual antennas for Multiple-Input Multiple-Output (MIMO).
To install an LTE antenna, do the following:
WARNING
Radiation hazard – risk of Radio Frequency (RF) exposure.
Antennas must be placed at a distance of at least 35 cm (13.8 in) from all persons
during normal operation. The antennas used for this product must not be located
or operating in conjunction with any other antenna or transmitter, except in accor-
dance with FCC multi-transmitter evaluation procedures.
16
RUGGEDCOM RX1400
Installation Manual, 09/2019, C79000-G8976-1103-13
