Technical Specifications
5
This chapter provides important technical specifications related to the device.
5.1 Power Supply Specifications
The RUGGEDCOM RX1400 includes one of the following internal power supplies:
Power Supply Type Input Range Internal Fuse Rating
a
Maximum Pow-
er Consumption
b
88-264 VAC
HI
98-300 VDC
±48V VDC ±36-72 VDC
3.15 A(T)
12-24 VDC 9-36 VDC
±12-24 VDC ±36 VDC
6.3 A(T)
< 15 W
a
(T) denotes time-delay fuse.
b
Power consumption varies based on the device configuration.
5.2 Failsafe Alarm Relay Specifications
Parameter Value (Resistive Load)
Max Switching Voltage 240 VAC
125 VDC
Rated Switching Current 2 A @ 240 VAC
0.15 A @ 125 VDC
2 A @ 30 VDC
Maximum Switching Capacity 150 W
500 VA
5.3 Fast Ethernet Port Specifications
The RUGGEDCOM RX1400 features four 10/100Base-TX fast Ethernet (FE) ports with
RJ45 connectors. For more information about the serial ports, refer to "Fast Ethernet
Ports (Page 29)".
Speed
a
100 Mbps
Connector RJ45
Duplex
a
FDX/HDX
RUGGEDCOM RX1400
Installation Manual, 09/2019, C79000-G8976-1103-13
35
