5-14
System Manual
C79000-G8576-C199-06
A PG-PLC link via SINEC H1 allows very advanced communication
between the partners. For example, the user software can be loaded into the
CPU 948 up to eight-times faster than with serial communication.
For this link you will need, in addition to the CPU 948, a CPU 143 (Version
w 2.1) in the PLC and a PG7xx with SINEC H1 connection and the STEP 5
single-tasking software from Version 6.0 or multi-tasking from Version 2.0.
Note
You cannot implement communication via SINEC H1 in parallel with the
serial interfaces.
Communication via SINEC H1 is described in detail in the CPU 948
Programming Guide.
Communication
via Backplane Bus
with SINEC H1
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
