System Manual
C79000-G8576-C199-06
5.7.2 Installation and Startup
!
Caution
Switch off the power supply before removing or inserting the module.
Proceed as follows to insert the CPU in the central controller:
Step Action
1 Release the upper locking bar of the central controller.
2 Select the correct slot (based on the labelling of the locking bar).
Insert the CPUs in the S5-135U/155U from slot 11.
3 Push the module evenly into the guide rail.
4 Secure the upper locking bar.
Proceed as follows to remove the CPU:
Step Action
1 Release the upper locking bar of the central controller.
2 Use the grips and gentle upward and downward motion to pull the
CPU forwards out of the CC.
Removing and
Inserting the
Module
Insertion
Removal
CPUs, Memor
y
Cards, Memor
y
Submodules, Interface Submodules
