5-122
System Manual
C79000-G8576-C199-06
5.11.7 Technical Specifications of the Interface Submodules
Important for the USA and Canada
The following approvals have been obtained:
UL Listing Mark
Underwriters Laboratories (UL) to Standard UL 508, Report E 85972
CSA Certification Mark
Canadian Standard Association (CSA) to Standard C 22.2 No. 142,
Report LR 63533
Degree of protection IP 00
Ambient temperature
in operation
for transporation and storage
0 to +55 °C
– 40 to +70 °C
Relative humidity 95% max. at 25 °C, no condensation
Supply voltage 5V $ 5%
24V + 25%/– 17%
Transmission rate
PG submodule
V.24 submodule
TTY submodule
RS422-A/485 submodule
SINEC L1 submodule
9 600 bps fixed
19 200 bps max.
9600 bps max.
19 200 bps max.
(when submodule is used in a CPU)
9600 bps fixed
Front connector, female
PG, RS422 A/485, SINEC L1
submodule
V.24, TTY submodule
15-pin Cannon
25-pin Cannon
Transmission cable Shielded four-wire line (five-wire line for
RS422 A) with braided shield and metal
housing on connector, grounding required at
both ends.
Line length
PG submodule
V.24 submodule
TTY submodule
RS422 A/485 submodule
SINEC L1 submodule
1000 m max.
16 m max.
1000 m max.
1200 m max.
1000 m max.
Current consumption at 5 V/24 V 5 V 24 V
PG submodule
V.24 submodule
TTY submodule
RS422 A/485 submodule
SINEC L1 submodule
40 mA max.
0.2 A max.
0.1 A max.
0.5 A max.
170 mA max.
380 mA
–
60 mA
–
100 mA
Design
Dimensions (WxHxD) 16.3 mm x 60 mm x 102.7 mm
Weight
per interface submodule Approx. 0.1 kg
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
