3-9
System Manual
C79000-G8576-C199-06
3.2.2 Example of Cabinet Assembly for EMC
The example of cabinet assembly in the figure shows the various measures,
the grounding of inactive metal parts and the connection of shielded cables.
This example applies only to grounded operation. Follow the points
numbered in the figure during assembly.
2
1
7
6
5
4
8
3
Figure 3-2 Example of Cabinet Assembly for EMC
Installation Guidelines
