4-74
System Manual
C79000-G8576-C199-06
4.5.3 Technical Specifications
Important for the USA and Canada
The following approvals have been obtained:
S UL-Recognition-Mark
Underwriters Laboratories (UL) to
Standard UL 508, Report E 116536
S CSA-Certification-Mark
Canadian Standard Association (CSA) to
Standard C 22.2 No. 142, Report LR 63534
6ES5 988-3LA11 6ES5 988-3NA11
Safety Specifications The power supply units comply with safety specifications
VDE 0805 / EN 60950 / IEC 950 / VDE 0160 and VDE
0106 Part 101.
Shock protection Only ensured in the installed state.
Data for EMC in the installed state See technical specifications of the S5-135U/155U CC
Safe isolation Is ensured.
Input
Rated input voltage 110 V AC (93.5-121 V),
220 V AC (187-242 V)
24 V DC (20 - 30 V)
Input frequency 50/60 Hz (48-63 Hz)
Input current I
i/pN
approx. 0.48 A
(and V
i/pN
= 120 V)
approx. 0.24 A
(and V
i/pN
= 230 V)
approx. 1 A
Peak inrush current I
i/pmax
< 5 A < 10 A
Max. heat dissipation at rated load (with fans) approx. 52 W approx. 24 W
Max. heat dissipation at rated load (without fans) approx. 12 W approx. 9 W
Stored energy time during power failure > 20 ms
Input fuse 1.5 A fast; 250 V; 2.4 A
2
s
Service life approx. 42.000 h at 40
o
C
Weight approx. 4 kg
Environmental data See technical specifications of the S5-135U/155U CC
Central Controllers and Expansion Units Power Suppl
y
Unit
s
