10.2 Installation
10.2.1 Possible Configurations
Recommended slots
Possible slots
ER 2
PS0 12345 67IM
ER 3
EU 187
EU 186
EU 185
EU 183
EU 184
EU 182
67311192735435159 75 83 91 107115 123
139
14715516399 131
10.2.2 Removing and Inserting
The module is pulled out by holding the handles and gently lifting and
lowering while pulling towards you. The monitoring module may only be
removed or inserted if the expansion unit is switched off.
Monitorin
Module
