5-83
System Manual
C79000-G8576-C199-06
5.9.3 Technical Specifications
Important for the USA and Canada
The following approvals have been obtained:
UL Listing Mark
Underwriters Laboratories (UL) to Standard UL 508, Report E 85972
CSA Certification Mark
Canadian Standard Association (CSA) to Standard C 22.2 No. 142,
Report LR 63533
Supply voltage during a read operation +5 V " 5 %
Current consumption during a read
operation (at 5 V)
200 mA max.
Access time t
ACC
250 ns
Operating temperature 0 to 55 °C
Storage temperature – 40 °C to 70 °C
Relative humidity Up to 95 % at 25 °C, no condensation
Number of programming cycles 10,000
Dimensions (H x D x W) 54 x 58 x 14 mm
Weight Approx. 40 g
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
