5-29
System Manual
C79000-G8576-C199-06
Data blocks DB 256, of which 253 are freely available
Data blocks DX 256, of which 253 are freely available
Organization blocks OB OB 1 to 39
(interfaces for operating system)
Integrated special function organization
blocks OB
OB 121, 122, 124-126, 131-133, 141-143, 150, 151, 153, 200,
202-205, 222, 223, 254, 255
Integrated serial interface PG interface
Optional serial interface PG interface with PG submodule
Backplane bus S5 bus
Dimensions (w x h x d) 40.6 x 233.4 x 160 mm
Weight Approx. 1 kg
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
