5-60
System Manual
C79000-G8576-C199-06
The module must be inserted at the correct slot in the central controller. The
backup battery must be fitted and in order for the CPU to start.
Step Action Result
1 Set the mode switch to STOP
2 Switch the system voltage on. The following LEDs must light
up on the CPU:
– Red STOP LED (flashing
rapidly)
– Red BASP LED
3 Hold the MC
1)
switch in the
OVERALL RESET setting
and simultaneously set the
mode switch from STOP to
RUN.
The red STOP LED is now
permanently lit.
1)
MC: Momentary-contact
Step Action Result
1 Set the mode switch to STOP.
2 Hold the MC switch in the
RESET setting and
simultaneously set the mode
switch from STOP to RUN.
– Red STOP LED goes off
– Green RUN LED lights up
– Red BASP LED goes off
The CPU is now in the RUN state
but still has no user program.
You can also carry out a manual restart of the CPU 928-3UA21 with the
mode switch. The CPU 928 Programming Guide will indicate when a manual
restart is permissible.
Step Action Result
1 Set the mode switch from
STOP to RUN.
– Red STOP LED goes off
– Green RUN LED lights up
– Red BASP LED goes off
For maintenance purposes or in the event of a fault, this startup without user
program in single-processor operation can serve to establish whether the CPU
is operating without errors.
Startup
Overall Reset
Reset
Restart
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
