5-94
System Manual
C79000-G8576-C199-06
Remove your interface submodule in the following steps:
Step Action
1 Switch off the power supply of your PLC.
2 Remove the CPU from the central controller.
3 Slacken the two locking screws of the submodule and pull it out
of the receptacle.
4 Fit another submodule (as already described) or close the
receptacle with its cover. Use the fixing screws of the submodule.
5 Insert the CPU in the central controller.
6 Switch the power supply of your PLC on again.
Note
Since the interface module is secured to the CPU with screws, interference
pulses are given a path to ground via the shield of the CPU.
Removal
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
