5-104
System Manual
C79000-G8576-C199-06
Connecting cable: CPU - DR 210/211, DR 230/231
You can use this connecting cable both with the V.24 and with the TTY
submodule. Ensure that you have the same type of interface in the CPU and
in the printer.
13
14
1
10
19
7
Shield
32
7
1
Receiver Transmitter
9
10
18
21
Housing
23
ReceiverTransmitter
525
Housing, GND
CPU DR 210/211, DR 230/231
RxD
TxD
CTS
TxD
RxD
Busy
TTY Assignments TTY Assignments
Figure 5-18 V.24 Submodule: Connecting Cable for CPU - DR 210/211, DR 230/231
CPUs, Memor
Cards, Memor
Submodules, Interface Submodules
