8-60
System Manual
C79000-G8576-C199-06
8.4.15 6ES5 456-4UB12 Digital Output Module
Rated supply voltage L 115 to 230 V AC (47 to 63 Hz)
Number of outputs 8, conditional short-circuit protection
1)
Isolation Yes, 8 outputs
Range for supply voltage 88 to 264 V AC
Fusing 3.5 A fast; 1 fuse per output
Output voltage
for logic 1
for logic 0
L– 1.5 V min.
30 V max.
Residual current at logic 0 5 mA max.
Switching current (resistive, inductive load)
ventilated
not ventilated
40 mA to 2 A;
2)
40 mA to 1 A;
2)
Switching current for lamps
ventilated
not ventilated
40 mA to 2 A;
40 mA to 1 A;
Contactor size 0 (Type 3TB40) to 14 (Type 3TB58) at 230 V AC;
00 (Type 3TJ ..) to 8 (Type 3TB52) at 115 V AC;
Max. inrush current for
≤ 3 ms
≤ 20 ms
≤ 50 ms
16 A
8 A
6.5 A
Switching capacity per module
for UL
for CSA
1440 VA max.
2000 VA max.
Permissible line length 300 m max. unshielded
Power supply
Digital section from system bus 5 V, 100 mA typical
Power dissipation (rated operation) 18.0 W
Enable input (F+/F–) Jumper in front connector
Voltage test to VDE 0160 Between two groups: 2000 V AC
Between group and ground point: 1500 V AC
Mechanical specifications
Dimensions (W x H x D) 40 mm x 255 mm x 195 mm
Weight Approx. 0.6 kg
1)
Protected by a fuse.
2)
Contactors of Series 3TJ can only be operated at 115 V AC.
Di
ital Input/Output Modules
