Operational error limit (0
o
C ... 60
o
C)
– voltage ranges except for 0-1.25 V, $1.25 V
– current ranges and 0-1.25 V, $1.25 V
0.2 %
0.2 %
Error signal
for overflow
for internal error
Yes (overflow bit set)
Yes (error bit (= E bit) set)
Single error
linearity
tolerance
polarity reversal error
0.02 %
0.05 %
0.05 %
Temperature error 0.005 %/K
Insulation rating To VDE 0160
Line length
- shielded
200 m max.
Front connector 43-way
Power dissipation of module 3.5 W typical
Weight Approx. 0.4 kg
Rated insulation voltage
(between channels and ground point) tested at
500 V
Analo
g
Input/Output Modules
