4-17
System Manual
C79000-G8576-C199-06
Modules and slot assignments of the EU 184U
Slot No.
3 11 19 27 35 43 51 59 67 75 83 91 99 107 115 123 131 139 147 155 163
Module type
IM 312-5
DI, DQ,
AI, AQ
Signal pre-processing
modules (IPs)
See current catalog ST 54.1 for slot numbers
Monitoring
module 313
Modules and slot assignments of the EU 185U
Slot No.
3 11 19 27 35 43 51 59 67 75 83 91 99 107 115 123 131 139 147 155 163
Module type
Coordinator 923 C
Communikation
processors (CPs)
IM 314 R
IM 300
IM 310, IM 134
IM 318
IM 317
IM 308
DI, DQ,
AI, AQ
Signal pre-processing
modules (IPs)
See current catalog ST 54.1 for slot numbers
Monitoring
module 313
Slots 19 to 75 are programmer MUX-capable
Modules and slot assignments of the EU 187U
Slot No.
3 19 35 51 67 83 99 115 131 147 163
Module type
IM 312-5
DI, DQ,
AI, AQ
Monitoring
module 313
