Siemens SICAM A8000 Series User Manual

Standard I/O Modules
SICAM A8000 Series, SICAM I/O Modules Unrestricted 25
DC8-012-2.06, Edition 09.2019
2.1.5 Block Diagram and External Circuitry
The following circuitry variants are examples, and do not relate exclusively to the depicted
inputs/outputs.
DI-811x
X2
Controller
BUS
IN D10
1 2
3
4 5
6
7
8
IN D11 IN D12 IN D13 IN D14 IN D17 IN D15 IN D16
COM10
9
10
X1
COM10
IN D00
1 2
3
4 5
6
7
8
IN D01 IN D02 IN D03 IN D04 IN D07 IN D05 IN D06
COM00
9
10
COM00
U+
U-
U+
U-
U+
U-
U+
U-
reinforced
insulation

Siemens SICAM A8000 Series Specifications

General

Modular Design	Yes
Operating Temperature Range	-40°C to +70°C
Communication Interface	Ethernet, RS485, RS232
Protection Class	IP20
Communication Protocols	IEC 61850, DNP3, Modbus, IEC 60870-5-104
Power Supply	24 V DC, 230 V AC
Mounting	DIN rail
Digital Inputs	Up to 32
Digital Outputs	Up to 16
Input Voltage Range	24 V DC to 230 V AC
