Siemens SICAM A8000 Series User Manual

Standard I/O Modules
64 Unrestricted SICAM A8000 Series, SICAM I/O Modules
DC8-012-2.06, Edition 09.2019
2.8.6.4 Medium Voltage/Low Voltage Measurement
The voltages in the medium-voltage network are determined by measuring the voltages from
the low-voltage network (secondary side of the transformer).
The voltage inputs U1, U2, U3 are directly connected with 240 V in the low-voltage network.
The current inputs I1, I2/IN, I3 are connected through the adaptor module CM-8820 with the
corresponding measuring sensors in the medium-voltage network.
In this configuration, the module determines the direction of phase fault and ground fault.
These connection diagrams are used for solidly grounded networks.
Note
The module
supports Dy-11 transformer type only. For this type, the secondary side of the transformer
lags the primary side by a phase
angle of 330°.

Siemens SICAM A8000 Series Specifications

General

Modular Design	Yes
Operating Temperature Range	-40°C to +70°C
Communication Interface	Ethernet, RS485, RS232
Protection Class	IP20
Communication Protocols	IEC 61850, DNP3, Modbus, IEC 60870-5-104
Power Supply	24 V DC, 230 V AC
Mounting	DIN rail
Digital Inputs	Up to 32
Digital Outputs	Up to 16
Input Voltage Range	24 V DC to 230 V AC
