Siemens SICAM A8000 Series User Manual

Standard I/O Modules
38 Unrestricted SICAM A8000 Series, SICAM I/O Modules
DC8-012-2.06, Edition 09.2019
2.5 DO-8212
2.5.1 Features
Binary output module
• Mounting on DIN rail
• 8 relay outputs (4 groups, 2 each)
• Galvanic insulation
• Switching voltage DC 24 to 220 V / AC 230 V
• The outputs can switch DC and also AC voltages
• Removable screw terminals
• Indication of function via LED
2.5.2 View
S
ICAM A8
00 0
D O-8212
RY
X4
X3
X2
X1

Siemens SICAM A8000 Series Specifications

General

Modular Design	Yes
Operating Temperature Range	-40°C to +70°C
Communication Interface	Ethernet, RS485, RS232
Protection Class	IP20
Communication Protocols	IEC 61850, DNP3, Modbus, IEC 60870-5-104
Power Supply	24 V DC, 230 V AC
Mounting	DIN rail
Digital Inputs	Up to 32
Digital Outputs	Up to 16
Input Voltage Range	24 V DC to 230 V AC
