2.4.3 Technical Data
Binary Inputs
16 binary inputs
• 2 groups, 8 inputs each
• Galvanic insulation
•
Each group has a common return of selectable polarity
Filter time 3 ms
Nominal voltage DC 220 V
Operating points ≤ 110 V logically "0"
≥ 165 V logically "1"
Input circuits DC 165…253 V
The circuits are operated by means of an external voltage
Rated current 0.3…0.7 mA at 165…253 V
Power Supply
Operating voltage DC 4.75…5.5 V 130 mW
The voltage is picked off at the system bus
Terminals Removable screw terminals (grid size 5.08)
Rated impulse voltage 4 kV (category III / AC 230 V)
Connection data X1, X2
Locking torque
2)
(PHOENIX)
(FCI)
0.5 Nm to 0.6 Nm
0.36 Nm to 0.44 Nm
AWG
min. 22
max. 12
Conductor cross section solid
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded with
ferrule without plastic sleeve
min. 0.33 mm²
max. 2.5 mm²
Conductor cross section stranded with
ferrule with plastic sleeve
min. 0.33 mm²
max. 2.5 mm²
2 wires stranded with ferrule without
plastic sleeve
min. 0.33 mm²
max. 1 mm²
2 wires stranded with TWIN ferrule with
plastic sleeve
min. 0.5 mm²
max. 1.31 mm²
Wire strip length
min. 6 mm
max. 7 mm
Length ferrule 10 mm
Dimensions 124 x 30 x 132 mm (L x W x H, dimensions w/o DIN rail)
Weight Approx. 249 g (inkl. bus module 12 g)
1)
if the sensor voltage of a group of binary inputs is monitored for failures (Parameter
SVM_monitoring), there is a dedicated binary input for each group (IN D07 and IN D17), this input
has a filter time of 2 ms
2)
the respective manufacturer is imprinted at the terminal (see section 1.2.4.1, Screw Terminal Types)
an ambient temperature of +65°C (horizontal mounting) / +45°C (vertical mounting) a derating
occurs. In this case, only a maximum of 13
inputs may be operated simultaneously.
