Standard I/O Modules
SICAM A8000 Series, SICAM I/O Modules Unrestricted 75
DC8-012-2.06, Edition 09.2019
Connection data X2 Locking torque 0.5 Nm
AWG
min. 24
max. 14
Conductor cross section solid
min. 0.2 mm²
max. 2.5 mm²
Conductor cross section stranded
min. 0.2 mm²
max. 2.5 mm²
Conductor cross section stranded with
ferrule without plastic sleeve
min. 0.25 mm²
max. 1.5 mm²
Conductor cross section stranded with
ferrule with plastic sleeve
min. 0.2 mm²
max. 1.5 mm²
2 wires stranded with ferrule without
plastic sleeve
min. 0.25 mm²
max. 0.34 mm²
Wire strip length 9 mm
Length ferrule 10 mm
Dimensions 124 x 30 x 132 mm (L x W x H, dimensions w/o DIN rail)
Weight Approx. 303 g
1)
the respective manufacturer is imprinted at the terminal (see section 1.2.4.1, Screw Terminal Types)
2)
plastic-insulated copper conductors (7 leads) with shield; up to 0.1 m (for side-by-side plugged
AI-8510 and CM-8820) single wires without shield are possible
Nominal voltage U
0
/U = 300/500 V, Temperature range -40…80°C
Note
For USA and Canada:
NRTL/SCC certified current transformers are required. Use only UL listed energy-
monitoring current transformers
.
Note
For each installed AI
-8510 a CM-8820 must be connected ahead, if the current measurement is used.
Thereby CM
-8820 modules may only be installed at the end of a module line (right-most), else the i
nternal
I/O bus is interrupted.
CM
-8820 modules may also be installed at a separate DIN rail
, whereby the maximal cable length must be
considered.
2.10.3.1 Accuracy of the Measured Values
Measured variable
Dependency of accuracy class acc. to
IEC 61557-12:2007-08 (K55)
Nominal current (input)
1 A 2% @ 50 Hz max. angle deviation 3°
2% @ 60 Hz max. angle deviation 3°
5 A 2% @ 50 Hz max. angle deviation 3°
3% @ 60 Hz max. angle deviation 3°
Nominal voltage (output) 3%
Nominal frequency
(49…51/59…61 Hz)
50 Hz 2% @ 0.2…10 A max. angle deviation 3°
60 Hz 3% @ 0.2…10 A max. angle deviation 3°
