11.1 Technical specifications of the ET 200SP F-TM ServoDrive
F-TM ServoDrive
98 Equipment Manual, 02/2020, A5E47579503-AA
Article number
6BK1136-6AB00-0BU0
Output voltage
Rated value, min.
24 V
Rated value, max.
48 V
Output current
Current output (rated value)
5 A
Output current, max.
10 A
Output frequency
420 Hz
Encoder supply
Number of outputs
1
5 V encoder supply
• Short-circuit protection
Yes
• Output current, max.
120 mA
Power
DC power consumption
300 W; At 50 V
Power loss
Power loss, typ.
3.5 W
Digital inputs
Number of digital inputs
1; + 1 input for message signal
Number of safety inputs
1; For STO, antivalent (2-pin) - 24 V DC
Encoder
Connectable encoders
• Incremental encoder (symmetrical)
No
Interrupts/diagnostics/status information
Alarms
• Diagnostic alarm
Yes
• Hardware interrupt
No
Diagnostic messages
• Monitoring the supply voltage
Yes
• Wire-break
Yes
• Short-circuit
No
• Group error
Yes
Diagnostics indication LED
• RUN LED
Yes
• ERROR LED
Yes
Integrated Functions
Position detection
• Incremental acquisition
Yes
