1
1-5
FM 351 Positioning Function Module
EWA 4NEB 720 6001-02
The mechanical transmission elements include:
Toothed belts
Spindle
Toothed rack/pinion
Hydraulic cylinder
Gear unit
Coupling systems
The CPU executes the controlling user program (sequential program). Data
and signals are interchanged via function blocks.
The PC/PG (programming device) is used for
Parameterization: You parameterize the FM 351 with the parameteriza-
tion interface.
Testing and setting up with the parameterization interface.
Programming: You program the FM 351 with function blocks which you
can directly link into the user program.
Mechanical Trans-
mission Elements
(Axis)
CPU
PC/PG
(Programming
Device)
Product Overview
