FM 351 Positioning Function Module
EWA 4NEB 720 6001-02
The cable connections for the encoders should be implemented using
shielded cables.
To ensure operation free of interference it is essential that the connecting en-
coder cables are grounded at both ends. The cable shield to the encoder must
be joined both to the shield connector block on the FM 351 Positioning Func-
tion Module as well as in the peripheral connector plug.
You will find the following subjects in this chapter:
Section Contens Page
4.1 Wiring the Power Controller 4-4
4.2 Description of the Encoder Interface 4-6
4.3 Connecting the Encoders 4-7
4.4 Description of the Peripheral Interface 4-9
4.5 Wiring the Peripheral Interface 4-13
Shielding
Chapter Overview
Wiring the FM 351
