Operating the device
6.1 Notes on operation
SIMATIC IPC MD-57A
Operating Instructions, 09/2023, A5E52775302-AA
57
The simultaneous use of MPI/DP Online
and a SIMATIC Memory Card can cause malfunctions.
Simultaneous use is not supported.
Terminate the use of the SIMATIC Memory Card before using MPI/DP.
6.1.4.6 Smart Card Reader
You can read smart cards with an integrated chip, such as plant ID cards, with the Smart Card
Reader.
When inserting the card, pay attention to the correct positioning of the card. The chip must
face upward.
6.1.5 General information about WLAN and Bluetooth
For information on the standard of WLAN and the Bluetooth version, refer to section "General
specifications (Page 83)".
The device is equipped with a network card for Wireless LAN (WLAN), i.e. you are not
assigned to a cable network.
You can find more detailed information about configuration and operation of the WLAN in
the online help of the WLAN network adapter.
Depending on the infrastructure and the access rights set by the network administrator, you
have exactly the same access to files, the printer and to the Internet with WLAN as with cable
network.
Depending on the surrounding conditions, you can create connections through walls or at
distances in the open air of up to 100 m.
The on-board network adapter operates based on the following standards:
The IEEE standard offers two modes of operation, the ad hoc mode (Peer to Peer) and the
infrastructure mode.
Ad hoc mode
The ad hoc network refers to a wireless network that is established directly between several
computers, whereby all computers must have a WLAN facility. No additional devices are
necessary.
Infrastructure mode
The infrastructure network uses access points to connect computers to wired networks with
the aid of WLAN. These can be a local network (e.g. company networks) or a global network
(e.g. Internet).
