Technical specifications
9.1 General specifications
SIMATIC IPC MD-57A
84 Operating Instructions, 09/2023, A5E52775302-AA
Immunity to discharges of static electricity
± 4 kV, contact discharge (according to IEC 61000–4–2; ESD)
± 8 kV, air discharge (according to IEC 61000-4-2; ESD)
Immunity to RF interference
10 V with 80% amplitude modulation with 1 kHz,
from 150 kHz to 80 MHz (according to IEC 61000-4-6)
10 V/m with 80 % amplitude modulation with 1kHz,
80 MHz to 1000 MHz (according to IEC 61000-4-3)
3 V/m with 80% amplitude modulation with 1 kHz,
1.4 GHz to 6 GHz (according to IEC 61000-4-3)
Magnetic field
30 A/m, 50 Hz and 60 Hz (according to IEC 61000-4-8)
Climatic conditions
Temperature
tested to IEC 60068-2-1, IEC 60068-2-2
Environment in operation
+ 5 °C to + 40 °C max. 10 °C/h (no condensation)
Battery temperature
+ 5 °C to + 45 °C:
• Battery is charging.
+ 45 °C to + 60 °C (high limit):
• Battery is charged with reduced current.
> 60 °C (high limit):
• Battery is not charging. Battery must cool below 45 °C
to be recharged.
NOTICE: Cooling down may take some time when op-
erating in a 40 °C environment.
Storage/transport
-20 °C to + 60 °C at max. 20 °C/h (no condensation)
Relative humidity
tested to IEC 60068-2-78, IEC 60068-2-30,
IEC 60068-2-14
During operation
5% to 85% at 30° C (no condensation)
Storage/transport
5% to 95% at 25° C (no condensation)
Mechanical ambient conditions
Vibration
Tested in accordance with DIN IEC 60068-2-6
Operation
10 to 58 Hz; amplitude 0.0375 mm
58 to 500 Hz; acceleration 4.9 m/s
2
Transport
5 to 9 Hz; amplitude 3.5 mm,
9 to 500 Hz: Acceleration 9.8 m/s
2
Shock
Tested in accordance with IEC 60068-2-27
Operation
Half-sine, 50 m/s
2
, 30 ms, 100 shocks
Storage/transport
Half-sine, 250 m/s
2
, 6 ms, 1000 shocks
Special features
Quality assurance
According to ISO 9001
Display
Type
TFT (Thin Film Transistor), 16: 9, anti-reflection
Size
344 x 194, corresponds to 15.6"
Screen resolution
1920 x 1080 (full HD)
Possible colors
maximum 256 k
Vertical frequency
60 Hz
Contrast
> 200 : 1
Brightness
typ. 300 cd/m
2
Permissible defective areas
light and dark pixel: Max. 10
Graphics
Graphics controller
•
Internal: Intel® Iris XE
• Dedicated: MXM module (option)
Graphics memory
Resolutions/frequencies/colors
According to the settings of the graphics driver
